Ideal for hauling heavy loads over long distances and up and down inclines.
Stainless Steel Motorized Utility Carts by Lakeside Manufacturing are ideal for hauling heavy loads over long distances and up and down inclines. The Lakeside 163422 Motorized Utility Cart has (3) shelves measuring 24-1/2" x 36" with a weight capacity of 1000-Lb. This motorized foodservice cart on wheels limits injuries when hauling heavy loads for long distances over steep inclines. This Lakeside motorized assisted cart has a self-contained electric motor transaxle and simple handle controls with two speed options. This utility cart's forward and reverse controls allow operator to push or pull cart. The 163422's static release floor belt dissipates static charge, while its power axle release allows for non-motorized use. This foodservice cart's emergency stop feature ensures operator safety and prevention of injuries. Its power cord holder allows for easy access to charge and neat tuck-away while in use. This cart has a quick charge battery system for quick and easy charging. Its all-welded stainless steel heavy-duty construction is easy to clean and sanitize. The 163422 has non-marking flat-free drive wheels, 2 ea. 8” swivel casters with brake for smooth maneuverability. Modify existing standard products with industry leading ship times from Lakeside’s U.S. factory! Lakeside is proudly made in the USA!
Current availability as soon as 20 business days
- Motorized assisted cart has a self-contained electric motor transaxle.
- Simple handle controls with two speed options.
- Forward and reverse controls allow operator to push or pull cart.
- Static release floor belt dissipates static charge, while power axle release allows for non-motorized use.
- Emergency stop feature to ensure operator safety and prevent injuries.
- Power cord holder for easy access to charge and neat tuck-away while in use.
- Quick charge battery system for quick and easy charging.
- All-welded stainless steel heavy-duty construction is easy to clean and sanitize.
- Non-marking flat-free drive wheels, 2 ea. 8” swivel casters with brake.
Specifications
Collapse| Brand | Lakeside |
|---|---|
| Caster Size-Front (in) | 8 |
| Caster Size-Rear (in) | 8 |
| Caster Type | Non-marking flat-free drive wheels, 2 ea 8" swivel casters with brake |
| Country of Origin | US |
| Item Dimensions (L x W x H) | 45.5 in x 24.5 in x 40.5 in |
| Model | Motorized |
| NSF | No |
| Number of Shelves | 3 |
| Proposition 65 Warning | This product can expose you to wood dust and chemicals including chromium, which are known to the State of California to cause cancer. For more information, go to: www.P65Warnings.ca.gov. |
| Shelf Clearance (in) | 11 3/8 |
| Shelf Dimensions | 24.5 in x 36 in |
| Shipping Class | 175 |
| Shipping Dimensions | 47 × 37.25 × 44 in |
| Shipping Method | LTL |
| Shipping Weight | 252 lbs |
| Weight Capacity (lbs) | 1000 |
Product Specification: Lakeside model 163422 is of welded stainless steel U-frame construction. Shelves are 14-gauge and U-frame is 1¼" x 1¼" x 1/8" angle stainless steel. The battery-operated power system features a 24-Volt DC transaxle drive and precision forward and reverse controls with auto-braking, and includes dual 35 Ah, AGM deep cycle batteries. Motorized cart has a speed range of 0.1 to 1.5 MPH at the low setting, and 0.1 to 3.0 MPH at the high setting. Battery charging system is 120 VAC, 1-phase, 47-63 Hz., with coiled cord and plug. Safety features include a 68 db. horn, emergency stop, keyed power-on lock, holding brake to keep unit from rolling down inclines when stopped, and automatic stop when operator releases control. A power axle release allows non-motorized use. Battery carriage features static release floor belt. Power wheels are 8" diameter flat-free non-marking with grip tread, and 8" casters are swivel with non-marking cushion-tread wheels.
Durability Index
Collapse| Durability Index | |||||
| Maximum Weight | 300lbs / 135KG | 500lbs / 230KG | 700lbs / 320KG | 1000lbs / 450KG | 1500lbs / 680KG |
| Weight Visualization | 75 plates | 150 plates | 250 plates | 100 12oz. cans | 30 cases of wine |
| Vinyl Tile | |||||
| Indoor Concrete | |||||
| Ceramic Tile | |||||
| Carpet | |||||
| Outdoor Uneven | |||||
| Daily Hour Usage | Up to 3 | 4 to 9 | 9 to 12 | 10 to 18 | Up to 24 hours |
| Ideal Usage | Dining area bussing, set-up tray station, soiled dish station | Dining room bussing, set-up tray station, soiled dish station. | Receiving goods, moving loads for warewashing | Receiving dock and storage room, loading and moving dishes and flatware. | Casinos and correctional facilities, receiving dock and warehousing |
| Legs Steel Gauge | 20 | 16 | 11 | 11 | 11 or 14 |
| Shelf Steel Gauge | 22 | 20 | 18 | 14 | 14 |
| Caster Size | 3-1/2” to 4” | 4” to 5” | 5" to 8” | 5" to 8” | 6" to 8” |
Manuals & Documents
Collapse
Options & Accessories
CollapseStandard products are available in a wide variety of common caster and bumper configurations or commercial grade vinyl and laminate finishes. These options along with accessories are listed below. Please contact us if you would like to further modify or customize a product to meet your needs.
Available Finish Options
Stainless Steel
Custom
CollapseChoose from a wide selection of proven product designs that can also be modified or customized to meet specific applications. Our experienced customer service team is ready to help with a quote today!
Design Your Own
